BARTEC SP9EX1 Smartphone

BARTEC SP9EX1 Smartphone

BARTEC SP9EX1 Smartphone

BARTEC SP9EX1 – World’s most compact 5G Smartphone for Zone 0/Zone 1/Division 1 – 17-S19P-31110110

Benefits

  • Compact and lightweight: Designed and optimized for all-day productivity and one hand use.
  • Intrinsically safe design: Over 1,000 dedicated components ensuring ex protection.
  • Fast 5G network connectivity: Qualcomm® QCM6490 processor supporting both public and private 5G network connectivity.
  • Low-light optimized camera: 48MP main camera and 8MP front camera for video calls.
  • Rugged: MIL-STD-810H and IP68 rated for water and dust resistance.

Datasheet
BARTEC SP9EX1 – Download>

BARTEC SP9EX1 Smartphone – Accessories – Download>

Description

Hardware Specifications

  • Processor: Qualcomm® QCM6490 Octa Core 2.7 GHz
  • Memory (RAM): 8 GB
  • Mass Storage: 128 GB
  • Display: 6.1″ AMOLED
  • Resolution: 1080 x 2340 pixels
  • Front Glass: Gorilla® Glass Victus® (generation 8)
  • Touch Function: Capacitive Touch (Stylus, bare or gloved fingertip input)
  • Size (L x W x H): 168.7 mm x 83.4 mm x 17.9 mm (6.6 inch x 3.3 inch x 0.7 inch)
  • Weight (with battery): 350 g (0.77 lb)
  • Battery: Lithium-ion battery 3.68 V/4300 mAh (15.8 Wh)

Connectivity and Network

  • SIM: Dual SIM (Nano SIM + eSIM)
  • Wireless Connections: WiFi 6, 5G
  • Radio Frequency Band:
    • 5G NR (Bands: 1-3, 5, 7, 8, 20, 25, 28, 38, 40, 41, 48, 66, 71, 77, 78)
    • LTE (Bands: 1-5, 7, 8, 12, 13, 17, 20, 28, 38, 40, 41, 48, 66, 71)
    • UMTS (Bands: 1, 2, 4, 5, 8)
    • GSM (Bands: 850, 900, 1800, 1900)
  • WLAN-WiFi: Wi-Fi 6 IEEE 802.11a/b/g/n/ac/ax, 2×2 MU-MIMO, Dual band Simultaneous (up to 2042 Mbps data rate and 160 MHz bandwidth)
  • Bluetooth: Bluetooth® 5.2 (including Low Energy long range and multiple broadcasts)
  • GNSS: GPS, A-GPS, Glonass, Galileo, and BeiDou
  • NFC: Read/write NFC tags (e.g., ISO 14443 Type A), contactless payments, and card emulation

Camera and Audio

  • Back Camera: 48 MP with Auto Focus
  • Front Camera: 8 MP
  • Voice & Audio: Two microphones, Vibrate alert, Speaker, Bluetooth wireless headset support, High-quality speakerphone
  • Notifications: Audible tone, multi-color LEDs, vibration

Additional Features and Accessories

  • Operating System: Android 13TM
  • Operating Temperature: -20 °C to +55 °C (-4 °F to +131 °F)
  • Protection Class (IEC 60529): IP68
  • External I/O: Charging pins, USB-C Port
  • Sensors: Accelerometer/Gyroscope, Magnetometer/Compass, Pressure/Barometer, Proximity, Ambient light
  • Buttons: 1x on/off button, 2x programmable function button (for PTT, Emergency call or other functions), 1x volume buttons (+/-)
  • Scope of Delivery: BARTEC SP9EX1 Smartphone, Battery, Battery tool, USB-C cable, Quick Start Guide
  • Required (not included): USB-C Charger (e.g., Wall Charger Type G7-S0Z0-0014/0015/0016/0017)

Marking

ATEX:
Ex II 1G Ex ia IIC T4 Ga
Ex II 2D Ex ia IIIC T135°C Db IP 64

IECEx:
Ex ia IIC T4 Ga
Ex ia IIIC T135°C Db IP 64

NEC/CEC 500/505:
Class I, Div 1, Groups A, B, C and D
Class II, Div 1, Groups E, F and G
Class III, T4
Zone 0, AEx ia IIC T4 Ga
Zone 21, Aex ia IIIC T135° Db
Ex ia IIC T4 Ga
Ex ia IIIC T135° Db

Ambient Temperature

Operating Temperature
-20°C to +55°C (-4 °F to +131 °F)

Charging Temperature
0°C to +40°C (+32°F to +113°F)
