Body / cab OT-58 brass (ON) – AISI-316L stainless steel (XX) marine grade copper free aluminium (on project request only)
Finishes full nickel plating treatment (brass material only)
Rubber rings EPDM rubber 50-60 shore hardness (standard supply) Silicon rubber 60 shore hardness (on demand only)
O-ring silicon rubber – 60 shore hardness
Skid washer nylon 6.0

Applications
For steel wire armoured cables (swa) for steel tape armoured cables and for lead inner sheath cables
Double Compression Type For Indoor And Outdoor Use
Provided armour clamping using clamping arrangements suitable for all armour wire/braid types
Internal lead device for electrical bond of cable lead inner sheath Double compression – under armour and overall of armour cable ( inner and outer sealing )
Sealing with proper resin into “chamber of sealing” ( on barrier type version “r” only )

PAP Metric Nickel Plated Brass               PAP Metric Nickel Plated Brass – NPT

PAP#00MON M16                                          PAP#00NON    M16
PAP#01MON M20                                          PAP#01NON    M20
PAP#02MON M25                                          PAP#02NON    M25
PAP#03MON M32                                          PAP#03NON    M32
PAP#04MON M40                                          PAP#04NON    M40
PAP#05MON M50                                          PAP#05NON    M50
PAP#06MON M63                                          PAP#06NON    M63
PAP#07MON M75                                          PAP#07NON    M75
PAP#08MON M90                                          PAP#08NON    M90
PAP#09MON M100                                       PAP#09NON    M100

PAP Metric Stainless Steel                         PAP Metric Stainless Steel – NPT

PAP#00MXX      M16                                       PAP#00NXX      M16
PAP#01MXX      M20                                       PAP#01NXX      M20
PAP#02MXX      M25                                       PAP#02NXX      M25
PAP#03MXX      M32                                       PAP#03NXX      M32
PAP#04MXX      M40                                       PAP#04NXX      M40
PAP#05MXX      M50                                       PAP#05NXX      M50
PAP#06MXX      M63                                       PAP#06NXX      M63
PAP#07MXX      M75                                       PAP#07NXX      M75
PAP#08MXX      M90                                       PAP#08NXX      M90
PAP#09MXX      M100                                    PAP#09NXX      M100
